Terex CRC1150s Portable Crushing & Screening Plant – Med Coarse
CRC1150S Closed Circuit Cone & Screen Plant
Location: Honey Brook
Availability: Immediate
CRC1150S Plant Specifications Highly Portable Triple Axle Plant
- Triple Axle Load = 58,500 lbs*
- King Pin Load = 52,300 lbs*
- Travel Height = 14’-0” (zero deg)
- Travel Width = 12’-0”
Cost Efficient, Sector Leading Technology
- 300 hp tried and tested floating head design with efficient roller bearings
- Large feed size: Standard Medium Course 190mm (7.5”), Optional Extra Course 220mm (8.66”)
- Large 65mm (2.55”) stroke producing good product shape & high capacity
- “Hammer-less” Concave retention system (quick-safe)
- No Welding lift ears for mantle change improving safety
- Spiral bevel drive gear train for long life, smooth running, low noise
- 160mm (6.3”) Tramp Clearance increasing protection
- Increased Clamp Hold Down Pressure allowing tighter settings
- Inspection ports through crusher frame for easy maintenance
- Metal detector on main feed conveyor
Options
- Electrical switchgear panel and hydraulic lift
- Hydraulic levelling, pinned run-on jacks or crank jacks (gas, 12v, 24v power unit)
- 24” mid plant cross conveyor
- Oversize tires
- Various power configurations (380v thru 575v, 50hz or 60hz)
